1. Infrastructure as Code(IaC)
Infrastructure as Code는 인프라를 코드로 관리하고 Provisioning하는 방법론이다.
서버, 네트워크, DB 등의 인프라 Resource 를 AWS, Azure 등의 Web GUI가 아닌, Code로 정의하고 관리함으로써 일관성과 효울성을 높일 수 있다.
특징
- 자동화 : 반복적인 인프라 설정 작업을 자동화하여 시간과 비용 절감 가능
- 일관성 : 동일한 코드로 동일한 환경을 언제든지 재현할 수 있어 환경 간 불일치 문제를 최소화 가능
- 버전 관리 : 코드 형태로 인프라를 관리하기 때문에 Git과 같은 버전 관리 시스템을 통해 변경 이력을 추적하고 복구할 수 있다.
- 협업 용이 : 개발자와 DevOps가 동일한 코드를 기반으로 협업할 수 있다.
주요 장점
- 신속한 배포 : 새로운 인프라 환경을 쉽고 빠르게 구축할 수 있어 개발 속도를 향상 시킬 수 있다.
- 오류 감소 : 자동화 된 스크립트를 사용하여 수동 설정에서 발생할 수 있는 실수를 줄일 수 있다.
- 확장성 : 대규모 인프라를 효율적으로 관리하고 확장할 수 있다.
- 비용 효율성 : 리소스 사용을 최적화하고 불필요한 비용을 줄일 수 있다.
- 테스트 가능성 : 인프라 변경사항을 미리 테스트하고 검증할 수 있어 안정성을 높일 수 있다.
IaC Tool
- HasiCorp Terraform
- AWS CloudFormation
- Azure Resource Manager
- Google Cloud Deplyment Manager
- Pulumi
2. Terraform
Terraform은 Hasicorp에서 개발한 Open Source IaC 도구로, 다양한 클라우드 플랫폼과 On-Premise 환경에서 인프라를 코드로 관리할 수 있다.
장점
- 플랜 기능 : 'terraform plan' 명령어를 통해 변경 사항을 미리 확인하고 검토할 수 있다.
- 상태 관리 : 현재 인프라 상태를 관리하여 변경 사항을 추적하고 일관성을 유지한다.
- 멀티 클라우드 지원 : AWS, Azure, GCP 등 다양한 클라우드 제공자를 지원하여 멀티 클라우드 환경에서도 사용 가능하다.
- 재사용성과 모듈화 : 코드의 모듈화를 통해 재사용성을 높이고 복잡한 인프라를 간단하게 관리할 수 있다.
3. Terraform 활용
멀티 클라우드 배포 예시
# AWS에 EC2 인스턴스 생성
provider "aws" {
region = "us-west-2"
}
resource "aws_instance" "web" {
ami = "ami-0c55b159cbfafe1f0"
instance_type = "t2.micro"
}
# Google Cloud에 Compute Instance 생성
provider "google" {
project = "my-gcp-project"
region = "us-central1"
}
resource "google_compute_instance" "default" {
name = "terraform-instance"
machine_type = "f1-micro"
zone = "us-central1-a"
boot_disk {
initialize_params {
image = "debian-cloud/debian-9"
}
}
network_interface {
network = "default"
access_config {}
}
}
AWS Infra 구축
- 사전 준비 사항 : AWS 계정, AWS CLI 설정, Terraform 설치
단계 1) 디렉토리 생성 및 초기화
mkdir terraform-aws-demo
cd terraform-aws-demo
terraform init
단계 2) Cloud Provider 설정
# main.tf
provider "aws" {
region = "us-west-2"
}
단계 3) VPC 생성
resource "aws_vpc" "main" {
cidr_block = "10.0.0.0/16"
enable_dns_support = true
enable_dns_hostnames = true
tags = {
Name = "demo-vpc"
}
}
단계 4) 서브넷 생성
resource "aws_subnet" "public_subnet" {
vpc_id = aws_vpc.main.id
cidr_block = "10.0.1.0/24"
availability_zone = "us-west-2a"
map_public_ip_on_launch = true
tags = {
Name = "demo-public-subnet"
}
}
resource "aws_subnet" "private_subnet" {
vpc_id = aws_vpc.main.id
cidr_block = "10.0.2.0/24"
availability_zone = "us-west-2a"
tags = {
Name = "demo-private-subnet"
}
}
단계 5) 인터넷 게이트 웨이 및 라우팅 테이블 생성
resource "aws_internet_gateway" "igw" {
vpc_id = aws_vpc.main.id
tags = {
Name = "demo-igw"
}
}
resource "aws_route_table" "public_rt" {
vpc_id = aws_vpc.main.id
route {
cidr_block = "0.0.0.0/0"
gateway_id = aws_internet_gateway.igw.id
}
tags = {
Name = "demo-public-rt"
}
}
resource "aws_route_table_association" "public_rt_assoc" {
subnet_id = aws_subnet.public_subnet.id
route_table_id = aws_route_table.public_rt.id
}
단계 6) NAT 게이트웨이 및 프라이빗 서브넷 라우팅 테이블 생성
resource "aws_eip" "nat_eip" {
vpc = true
}
resource "aws_nat_gateway" "nat" {
allocation_id = aws_eip.nat_eip.id
subnet_id = aws_subnet.public_subnet.id
tags = {
Name = "demo-nat-gateway"
}
}
resource "aws_route_table" "private_rt" {
vpc_id = aws_vpc.main.id
route {
cidr_block = "0.0.0.0/0"
nat_gateway_id = aws_nat_gateway.nat.id
}
tags = {
Name = "demo-private-rt"
}
}
resource "aws_route_table_association" "private_rt_assoc" {
subnet_id = aws_subnet.private_subnet.id
route_table_id = aws_route_table.private_rt.id
}
단계 7) 변경 사항 검토 및 생성
terraform plan
terraform apply
단계 8) 인프라 삭제
terraform destroy
주요 포인트
- 재사용성 : 동일한 코드에서 약간 수정하여 다른 환경이나 리전에 적용할 수 있다.
- 일관성 : 코드로 정의된 인프라는 항상 동일한 방식으로 배포된다.
- 가독성 : 선언적인 구문을 사용하여 인프라의 구조와 의도를 쉽게 파악할 수 있다.
4. 기타 활용 사례
- 자동 스케일링 및 로드 밸런싱 : Terraform을 사용하여 자동 스케일링 그룹과 로드 밸런서를 설정하여 트래픽 변화에 유연하게 대응 가능
- 컨테이너 오케스트레이션 : Kubernetes 클러스터를 Terraform으로 프로비저닝하고 관리하여 컨테이너화된 애플리케이션을 효율적으로 배포할 수 있다.
- CI/CD 파이프라인 : Terraform을 CI/CD 파이프라인에 통합하여 코드 변경사항과 함께 인프라 변경 사항을 자동으로 배포하고 관리할 수 있다.
- 멀티 클라우드 및 하이브리드 클라우드 관리 : 여러 클라우드 제공자와 온프레미스 환경을 동시에 관리하여 유연하고 탄력적인 인프라를 구축할 수 있다.
